Home > Products > CATV/MATV/Satellite Splitter (Indoor) > "S"Type 5-1000/2500 MHz Splitter

Loading...
S206


Specification Frequency Range (MHz) Insertion Loss In-Out     (Min.dB) Return Loss In (Min.dB) Return Loss Out
(Min.dB)
Isolation Out-Out (Min.dB)
6-way Splitter 5-47 11.5 10 10 20
47-1000 11.5 10 10 20
1000-2050 17.0 10 10 20
2050-2150 17.5 10 10 20
2150-2300 18.0 10 10 20
2300-2500 19.5 10 10 20
